Trying to recreate the "Kinetic Gate" outputs of the Plan B Model 32 joystick using a Flight of Harmony Choices and Doepfer A-156 Dual Quantizer.

Patch:

X and Y voltage outputs from Choices are mixed together and sent to the CV in on the A-156. Trigger out from the quantizer to an envelope channel on Maths, Maths CV out to VCA CV in.

Quantizer CV out to 1v/oct input on VCO (in this case an e350 Morphing Terrarium).

(copies of the X and Y outputs are sent to the X and Y morph inputs on the e350)

That's it! Changing the quantizer settings changes the voltage output obviously, but also the amount of new voltages being created, which in turn affects the number of triggers it will be spitting out.
