HORIZONTAL DRILLING

The tunnel borer machine has 3 main sections, the cutterhead, hydraulic bracing system and conveyor.
The cutterhead rotates a full 360 degrees. As it pushes against the rock, it chips off loose material.
The chips fall into large openings in the cutterhead, which leads to a conveyor belt system at the rear of the machine.
