Serial Alphabet

Name: Serial Alphabet
Uploaded: 2009-06-08T05:26:27+00:00
Duration: 1 min 26 s
Channel: MightyOhm
Description: All 26 letters of the alphabet displayed as 3.3V RS232 serial bytes. (115200 baud, 8N1) Screen captures were made using an Agilent DSO1014A digital storage oscilloscope.

All 26 letters of the alphabet displayed as 3.3V RS232 serial bytes.  (115200 baud, 8N1)  Screen captures were made using an Agilent DSO1014A digital storage oscilloscope.
